High Performance Telescopic Handler Crane for Loading Materials / Short Distance Transporting

China High Performance Telescopic Handler Crane for Loading Materials / Short Distance Transporting supplier
High Performance Telescopic Handler Crane for Loading Materials / Short Distance Transporting supplier High Performance Telescopic Handler Crane for Loading Materials / Short Distance Transporting supplier High Performance Telescopic Handler Crane for Loading Materials / Short Distance Transporting supplier High Performance Telescopic Handler Crane for Loading Materials / Short Distance Transporting supplier

Large Image :  High Performance Telescopic Handler Crane for Loading Materials / Short Distance Transporting

Product Details:

Place of Origin: China
Brand Name: Visbull
Certification: ISO / CE
Model Number: SCZ40-4

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Naked packing in container
Delivery Time: 20 working days after received L/C or your deposit
Payment Terms: L/C at sight, T/T or western Union
Supply Ability: 1500 units per month
Contact Now
Detailed Product Description
Power Type: Diesel Max Lifting Capacity: 4000 Kg
Max Horizontal Reach: 5500 Mm Max Lifting Height: 9200 Mm
Wheel Base: 2520 Mm Min Turning Radius: 7250 Mm
Max Travel Speed: 30 Km/h Min Height Of Forks: 350 Mm
Operating Weight: 9440kg
High Light:

extendable boom forklift

,

telescopic forklift hire

High Performance Telescopic Handler Crane for Loading Materials / Short Distance Transporting





4Ton Hydraulic Telescopic Forklift With Mutifuctional Equipments SCZ40-4 With Max Horizontal Reach 5500MM



SCZ40-4 type telescopic forklift loader ,which uses the four-wheel drive,rigid suspension; hydraulic mechanical transmission, hydraulic power steering and hydraulic brake, rear wheel steering. Operating device for the two quadrangle telescopic arm work, the standard model with a fork or crane devices. The car can be used for container pallet container supplies dig boxes, packing or fork lift operations and supplies for all kinds of container loading and unloading, stacking and short-distance transport operations.

The car is suitable in a variety of work environments operations, is mining, business, construction, building materials, ports, municipal engineering and other industries handling, lifting, transportation is the ideal equipment. The car is also equipped with bucket, hook, crane and other various attachments for users to select, install and use. Its loading height and off-road performance is unmatched by ordinary truck.


Specifications:

Item

Unit

Parameter

Max Hoisting Weight

(with fork)

kg

4000

The Distance of Load Center(Tyre-fore to

load center of hook)/ Hoisting Weight

(with hook)

mm

3500

4000

4500

5000

5500

Kg

3000

2750

2500

2250

2000

Max. Lifting Height of Main Hook

(Main hook to ground)

mm

front suspension point

upper face of fork

9200

6250

Max Horizontal Reach

mm

Tyre-fore to Frong Lifting Point

Tyre-fore to Vertical

Segment of Fork

5500

3200

Max. Traveling Speed

km/h

30

Min. Ground Clearance

mm

350

Min .turning Radius

mm

7250

Grade ability

%

20

The Angle of Lean Up/Down

m/s

15°/25°

Tread

mm

1900

Wheel base

mm

2520

Deadweight

mm

9440

Overall Dimension (L×W×H)(Except the tool’s)

mm

6100mm×2280mm×2700

Engine

(CUMMINS)

Model



4BT3.9-C80

Rated power

kw

60

Rated speed

r/min

2000

Peak Torque



330N.m/1500r/min

Displace

ment

L

3.9

Tire

Front



16/70-24

Rear



10.00-20



Description:
The working device is two-segment,quadrilateral telescopic boom,and fork lateral displacement unit adopted in normal type.

This boom loader is mainly used to handle the unloading and loading of materials which piled on trays to containers as well as pilling,stocking and short distance transporting.It is a kind of multi-purpose using,efficient and convenient machine for loading and unloading, hosting,transporting in mineral yards,planet,construction spots,ports,public works, furthermore optional accessories could be choose by user include bucket, hook, boom.The loading heigh and the cross country performance of our products are much excellent than regular forklift trucks.

High Performance Telescopic Handler Crane for Loading Materials / Short Distance Transporting

High Performance Telescopic Handler Crane for Loading Materials / Short Distance Transporting
