| Power Type: | Diesel | Rated Capacity: | 3500 Kg |
|---|---|---|---|
| Load Center: | 500 Mm | Mast Lifting Height: | 3000 Mm |
| Max. Grade Ability: | 20% | Free Lift Height: | 160 Mm |
| Fork Size(L*W*T): | 1070×125×45 Mm | Min Turning Radius: | 2420 Mm |
| Max Driving Speeds: | 19 / 19 Km/h | Total Weight: | 4700 Kg |
| High Light: | heavy duty forklifts,power lift forklift |
||
Hydraulic Industrial Forklift Truck , Full Automatic Stepless Speed Adjustable Electric Forklift Truck
3.5Ton Diesel Forklift Truck Balance Weight Type CPCD35 Has Optional Cabin And Air Conditioner
Specifications:
|
Model |
Unit |
CPCD35 |
|
|
Power type |
|
Diesel |
|
|
Rated capacity |
kg |
3500 |
|
|
Load center |
mm |
500 |
|
|
Mast Lifting height |
mm |
3000 |
|
|
Free lift height |
mm |
170 |
|
|
Fork size(L*W*T) |
mm |
1070×125×45 |
|
|
Tilting Angles(Front/Rear) |
deg |
6°/12° |
|
|
Front overhang |
mm |
498 |
|
|
Exterior Size |
Length without fork |
mm |
2693 |
|
Overall width |
mm |
1225 |
|
|
Mast drop |
mm |
2180 |
|
|
Max. lift |
mm |
4262 |
|
|
Front-wheel Overhead |
mm |
2090 |
|
|
Min Turning Radius |
mm |
2420 |
|
|
Min. intersecting aisle |
mm |
2400 |
|
|
|
Max Driving speeds |
km/h |
19/19 |
|
Lifting speeds |
mm/s |
330/370 |
|
|
Lowering speeds |
mm/s |
350/400 |
|
|
Max. grade ability |
% |
20 |
|
|
Total weight |
kg |
4700 |
|
|
Tires |
Front |
|
28*9-15-12PR |
|
Rear |
|
6.5-10-10PR |
|
|
Wheelbase |
mm |
1700 |
|
|
|
Front |
mm |
1000 |
|
Rear |
mm |
970 |
|
|
Min. ground clearance |
mm |
135 |
|
|
Engine |
Model |
|
Isuzu C240 Engine |
|
Rated output |
kw/rpm |
42/2650 |
|
|
Rated torque |
N.m/rpm |
174/1800 |
|
|
No. of cylinder |
|
4 |
|
|
Displacement |
L |
2.98 |
|
|
Fuel tank capacity |
L |
60 |
|
Description:
1. Full automatic stepless speed adjustable electric controlled transmission gear box guarantee the forklift with superior travel and track performance.
2. New type engine with super power has features of good performance , low fuel consumption, enough power reservation ,EPA standard displacement level.
3. Advanced hydraulic system, 2-speed lifting system can automatically adjust its lifting speed according to the goods weight ,electric controlled valve can work safety and efficiently.
4. Eqiupment with heavy –duty driving axle with big bearing capacity and enhanced oil cooled braking system, increase the reliabillgy and durability.
5. Equipments with fine safety monitor to make it has clear visibility, 3-step switch-lock confirmation device to guarantee safe work.
6.Centralize controlled lever and stimulant automatic instrument is easy operated and has beautiful appearance.
7. high strength mast of CJ shape welded by refined steel, has features of high strength and rigid.Sweden "H" typed ELME spreader up to advanced international level, enhance its operation and reliability.
8. New cabin has comfort windows and wide view, with air conditioner can modify the operative circumstance.
9. The whole truck has advanced technology, beautiful, appearance, reasonable layout, is the best new model.
Main Features:
LCD Dashboard
Our exquisite dashboard can present clear display, elegant looking & practical meter function
Streamlined Counter Weight
The simplified streamlined design can ensure both graceful appearance & swift turning in narrow aisle space
Smart Steering Wheel
The smart wheel application has greatly increased easy& efficient operation for drivers
Wholly Integrated Frame
Our fully welded frame could enhance safety and overall stability substantially
Sturdy Mast
German originally imported Mast steel has tremendously improved its hardness & strength and effectively avoid mast deformation
Transmission
By comparison, G.C Power self-innovative transmission possess unique features in minimum vibration, swift response in quick starting & accelerating, easy assemble & maintenance etc
Hydraulic Steering
Our fully hydraulic system can guarantee highly precise and smooth steering
Tough Axle
Heavy load can be easily lifted by our tough & durable axle
