Product Details:
Payment & Shipping Terms:
|
| Rated Power: | 50 HP | Rated Loading Weight: | 720 Kg |
|---|---|---|---|
| Bucket Capacity: | 0.35 M3 | Weight: | 3200 Kg |
| Max.Travel Speed: | 13.6 M/h | Grade Ability: | 20 ° |
| Dumping Reach: | 495 Mm | Break Force: | >20kN |
| High Light: | tracked skid steer,skid steer equipment |
||
Optimum Hydraulic System Small Skid Steer Loaders 0.35m3 Bucket Capacity
50HP Power Small Skid Steer Loader XT740 With Bobcat Attachments Full Hydraulic System
Introduction of XCMG skid steer loader XT740 :
Reliable and durable frame work prolong the machine using life.
The original imported engine generates super power and low exhaust,which makes the macine
environmental.
Optimum hydraulic system design grantee efficient work.
The integral FOPS&ROPS and human-engineering designed cabin makes work comfortable.
Adopting internationally univeral quick coupler can make changing attachments in few minutes.
Convenient maintenance.
Detailed Product Description
Technology parameter:
The hydraulic oil tank, fuel tank and the chassis are integrated in one structure, which saves space, and the machine is more rigid. The machine can be applicable to various kinds of work.
The proportional controlled pilot control lever is easy to operate and saves effort, the operator can get skilled to operate the machine in a short time and not easily get tired. The leveling valve can keep the bucket level during the boom lift.
The cab is capacious and has good visibility, all the instruments are located at the front for easy inspection, and all the buttons and switches are within hand’s reach. The safety rails can prevent the operator from leaving the seat unexpectedly, and there are also four safety measures to ensure the operator’s safety.
It adopts the commonly used quick coupler; all types of attachments can be installed quickly and conveniently. The pipe joint is also standard. And most of the attachments produced by other manufacturers can be applicable on XT740.
The cab can be turned forward in a large angle. There are two modes to control the engine throttle: manual and foot pedal control, which makes it much more convenient for the operator. Various kinds of attachments can be mounted on
Main Technical Parameter of XCMG skid steer loader XT740 :
|
Overall dimentions L×W×H |
3272mm×1600mm×2025mm |
|
Operating weight |
3200kg |
|
Tyre |
10-16.5NHS 10RP |
|
Bucket capacity |
0.35m3 |
|
Rated load |
720kg |
|
Dumping clearance |
2340mm |
|
Dumping reach |
495mm |
|
Raising time |
<5s |
|
Total cycling time |
<10s |
|
Breakout force |
>20kN |
|
Wheel base |
996mm |
|
Tread |
1300mm |
|
Engine |
Xinchai |
|
Rated power |
37 kW |
|
Rated speed |
2800r/min |
|
Max traveling speed |
13.6km/h |
