Asphalt Cold Milling Machine for 160mm Depth 500mm Width Max Milling Road Maintenance

China Asphalt Cold Milling Machine for 160mm Depth 500mm Width Max Milling Road Maintenance supplier
Asphalt Cold Milling Machine for 160mm Depth 500mm Width Max Milling Road Maintenance supplier Asphalt Cold Milling Machine for 160mm Depth 500mm Width Max Milling Road Maintenance supplier Asphalt Cold Milling Machine for 160mm Depth 500mm Width Max Milling Road Maintenance supplier Asphalt Cold Milling Machine for 160mm Depth 500mm Width Max Milling Road Maintenance supplier

Large Image :  Asphalt Cold Milling Machine for 160mm Depth 500mm Width Max Milling Road Maintenance

Product Details:

Place of Origin: China
Brand Name: Visbull
Certification: ISO9001:2008, CE
Model Number: XM50K

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Naked packing in container
Delivery Time: 10 working days after received L/C or your deposit
Payment Terms: L/C at sight, T/T or western Union
Supply Ability: 1500 units per month
Contact Now
Detailed Product Description
Product Name: Cold Milling Machine Rated Power: 82kw
Max. Milling Depth: 160mm Max. Milling Width: 500mm
Travel Speed: 0-6km/h Operating Speed: 0-30m/min
Drum Diameter With Tools: 660mm Operating Weight: 7000kg
High Light:

pavement milling machine

,

asphalt grinding equipment

Asphalt Cold Milling Machine for 160mm Depth * 500mm Width Max Milling Road Maintenance



50CM Cold Milling Machinery XCMG XM50K Asphalt Type Milling Machine With 82KW Rated Power



XM Series milling machine is one of the main asphalt concrete road maintenance equipment, mainly used for large-scale highways, urban roads, airports, freight yard, etc for renovation of asphalt pavement. One-time removal of entire concrete overlay. It can also be used for cleaning protuberance, oil layers, retieulation and vehicle tracks as well as road trench, tunnel excavation. cement road surface roughening and dislocation smothness.

The equipment features advanced performance, high efficiency, simple process, easy control of milling depth, flexible operation, good maneuverability and the old material recycling and utilization. It is an ideal equipment for pavement maintenance and renovation.



Performance and characteristic

• Hydraulic driving milling drum has the obvious characteristics of stable milling and high efficiency.

• Compact three-wheeled machine with front-wheel drive .The advance speed is infinitely variable in both gear which can be suitable for the requirement of different working conditions.

• The front steering driving axie has large steering angle and small turming radius ,can mill along the manhole covers.

• The high-strength and high wear resistance imported cutter head and cutter rest have long service life and low construction cost.

• The imported hydraulic elements have high working reliability.

• Excellent welting milling performance with right rear leg which can be fast swung into the frame makes the milling drum attached to the road edge stone or wall for milling operation.

• Hydraulic handheld breakers and rumble strip equipment can be selected.



Specification:



Model





XM50K

Engine

Model



4BTA3.9-C110

Rated Power/ Speed

kw/rpm

82/ 2200

Operating Speed

m/min

0~30



Driving Speed

km/h

0~6

Specifications

Gradeability

%

60

Ground clearance

mm

≤120

Operating Weight

kg

7000

Max Milling Width

mm

500



Max Milling Depth

mm

160

Operating Parameters

Number of tools



44

Drum diameter with tools

mm

660

  Overall Size

Machinery (LX WX H)

mm

3470X1895X3070

Conveyor (LX WX H)

mm





Fuel tank

L

140

Tank Capacity

Hydraulic Oil Tank

L

120

Water tank

L

300







Walking Way



Wheel

Asphalt Cold Milling Machine for 160mm Depth 500mm Width Max Milling Road Maintenance
