6M - 12M Hydraulic Boom Lift , mobile aerial platform 200KG Rated Capacity

China 6M - 12M Hydraulic Boom Lift , mobile aerial platform 200KG Rated Capacity supplier

Large Image :  6M - 12M Hydraulic Boom Lift , mobile aerial platform 200KG Rated Capacity

Product Details:

Place of Origin: China
Brand Name: KUDAT
Certification: CE
Model Number: GTWY12-200

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Naked packing
Delivery Time: 30 working days after received your deposit
Payment Terms: L/C at sight, T/T . Western Union, MoneyGram
Supply Ability: 500 units per month
Detailed Product Description
Platform Height Maximum: 6m Max. Work Height: 7.8m
Platform Size: 1230*540mm Net Weight: 520kg
Lift Capacity: 200kg Power Source: AC/DC
Material: Aluminum Alloy Application: Aerial Work

6M - 12M Hydraulic Boom Lift , mobile aerial platform 200KG Rated Capacity



Description:

Double Mast Aluminum Aerial Work Platforms are used for one or two person aerial working,

which made up of high grade aluminum profile in double mast structure and equipped with the

universal wheels, easily pushed around to the designated sites, beautiful structure, compact main body, light weighted, safe and reliable; It is operated by the telescopic cylinder which is strong and reliable working and the control panels are available on the lift platforms and ground. The platform is equipped with the ladder.
It is mainly used for the installation and maintenance of the narrow spaces such as star hotels, modern workshops,business hall, hotels, lobby, restaurant, railway stations, exhibition hall and shopping malls; it is a good helper for the equipment maintenance, paint decoration; Easily going through the regular doors and elevators, of low energy consumption, no pollution, do no damage to the grounds. The lifting height ranges from 6m to 12m and lifting capacity is 200kg.The power sources could be 220V, 380V or chargeable battery.



Features:

1. Most rigid aluminum alloy profile
2. Auxiliary platform lowering
3. Multiple-guide pulley on mast
4. Durable base system
5. Chassis with level gauge
6. DC working power on the platform
7. Easily rolls through a narrow space
8. Emergency stop button
9. Over- load protection
10. Built-in pressure release valve
11. Dual activated up/down switch
12. Locking Key Switch
13. Optional extended platform
14. Entry ladder



Specifications:

Model   GTWY6-200 GTWY8-200 GTWY10-200 GTWY12-200
Capacity kg 200 200 200 200
Max.Platform Height mm 6000 8000 10000 12000
Ground Clearance 80
Working Platform Size 1230x540 1350x540 1470x540
Unfolding Size 2230x1950 2230x2070 2230x2190
Power AC V 220
DC 24
Battery V/Ah 2x12/85
Charger V/A 24/10
Lifting Motor AC v/kw 220/1.1
DC 24/1.5
Overall Length mm 1460 1460 1580 1700
Overall Width 920
Overall Height 1980
Overall Weight AC kg 520 560 610 670
DC 550 590 640 700
