CE Approved 11M Electric Portable Hydraulic Boom Lift , Man Lift For Aerial Work

China CE Approved 11M Electric Portable Hydraulic Boom Lift , Man Lift For Aerial Work supplier
CE Approved 11M Electric Portable Hydraulic Boom Lift , Man Lift For Aerial Work supplier CE Approved 11M Electric Portable Hydraulic Boom Lift , Man Lift For Aerial Work supplier CE Approved 11M Electric Portable Hydraulic Boom Lift , Man Lift For Aerial Work supplier

Large Image :  CE Approved 11M Electric Portable Hydraulic Boom Lift , Man Lift For Aerial Work

Product Details:

Place of Origin: China
Brand Name: Visbull
Certification: CE
Model Number: SJY0.3-11

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Naked packing
Delivery Time: 30 working days after received your deposit
Payment Terms: L/C at sight, T/T . Western Union, MoneyGram
Supply Ability: 500 units per month
Contact Now
Detailed Product Description
Platform Height Maximum: 11m Max. Work Height: 12.8m
Platform Size: 2100*1140mm Paint:: Epoxy Paint
Net Weight: 1380kg Lift Capacity: 300kg
Power Source: AC/DC Material: High-duty Steel Structure
High Light:

telescopic forklift hire

,

Articulating Boom Lift

CE Approved 11M Electric Portable Hydraulic Boom Lift , Man Lift For Aerial Work



Description:



Small electric hydraulic mobile scissor lift China is the professional high-altitude operation equipment and and widely used for the installations and maintenance, at places like construction sites workshops,warehouse,granary,bus/railway stations,hotels,airports,gas station and aerial pipeline.



Features:

A.Made of high intensity manganese steel tubes, never deformed.
B.Antiskid upper platform plate and 1000mm height guardrail to guarantee opertor's safety.
C.Anti explosion valve to prevent upper platform from dropping suddenly when any emergency.You can open the emergency decline valve to lower the platform to the home position.
D.Spillover valve: It can prevent high pressure when the machine moves up to adjust work pressure.
E.Special made casting steel hinge ear, well wearable , with a long serve life.



Hydraulic scissor lift platform advantage:

Lifting mechanism were made with high strength manganese steel major form.
To prevent lifting platform overload safety device.
Have a safety protection valve to prevent hydraulic pipeline rupture.
Outage case emergency drop device.
Lifting platform power matching
Ac 380 v power supply (general configuration)
Ac 220 v power supply
Dc power DC24V
Manual hydraulic pump power manual/electric dual power
Ac and dc dual power.



Specifications:

Model Unit KDSJY0.3-11
Rated capacity kg 300
Plate height(max) mm 11000
Plate height (min) mm 1560
Plate size(l*w) mm 2100*1140
Working voltage v AC380,AC220,or AC110
Working voltage v DC24,or AC_DC24
Motor power 380v 1.5kw
Motor power 220v 2.2kw
Overall length mm 2280
Overall width mm 1340
Overall height mm 2596
Met weight kg 1380
