4 Ton Balance Weight Industrial Lift Trucks With Side Shift / Automatic Transmission

China 4 Ton Balance Weight Industrial Lift Trucks With Side Shift / Automatic Transmission supplier

Large Image :  4 Ton Balance Weight Industrial Lift Trucks With Side Shift / Automatic Transmission

Product Details:

Place of Origin: CHINA
Brand Name: KUDAT
Certification: ISO / CE
Model Number: CPCD40

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Naked packing in container
Delivery Time: 15 working days after received L/C or your deposit
Payment Terms: L/C at sight, T/T or western Union
Supply Ability: 1500 units per month
Detailed Product Description
Power Type: Diesel Rated Capacity: 4000 Kg
Load Center: 500 Mm Mast Lifting Height: 3000 Mm
Max. Grade Ability: 20% Free Lift Height: 150 Mm
Fork Size(L*W*T): 1070×150×50 Mm Min Turning Radius: 2720 Mm
Max Driving Speeds: 19.5 / 20 Km/h Total Weight: 5100 Kg

Widely Used 4 Ton Balance Weight Type Diesel Forklift Truck With Side Shift And Automatic Transmission





Specifications:



Model

Unit

CPCD40

CPCD45

Power type



Diesel

Rated capacity

kg

4000

4500

Load center

mm

500

Mast Lifting height

mm

3000

Free lift height

mm

150

Fork size(L*W*T)

mm

1070×150×50

Tilting Angles(Front/Rear)

deg

6°/12°

Front overhang

mm

490

545



Exterior Size

Length without fork

mm

2885

2900

Overall width

mm

1480

Mast drop

mm

2230

Max.lift

mm

4200

Front-wheel Overhead

mm

2300

Min Turning Radius

mm

2720

2740

Min.intersecting aisle

mm

3345

3365



Speeds

Max Driving speeds

km/h

19.5/20

19/21

Lifting speeds

mm/s

470/520

500/530

Lowering speeds

mm/s

≤600

Max.grade ability

%

25/20

27/20

Total weight

kg

5100

6400


Tires

Front



250-15-16PR

300-15-18PR

Rear



6.50-10-10PR

7.00-12-12PR

Wheelbase

mm

1900

2000


Tread

Front

mm

1160

1180

Rear

mm

1065

1190

Min. ground clearance

mm

145

155



Engine

Model



Isuzu 4JG2 Engine

Isuzu 6BG1 Engine

Rated output

kw/rpm

37/2650

59/2400

Rated torque

N.m/rpm

148/1800

288/1600

No.of cylinder



4

Displacement

L

3.17

4.33

Fuel tank capacity

L

65

95





Features:



Ergonomically designed the controlling parts for the excellent combination, and operator comfort and ease of operation with excellent vision, more and more reducing the fatigue of drivers.

High power, positive powered performance, distinguished performance for excellent starting in low temperature,. The indexes of noise, vibration, exhausting reach the standard I of European.

New type hydraulic steering system provides the sensitive, comfortable, accurate steering performance. The greatest extent to exert the flexibility in the narrow workplace.

Imported multi-way valve, oil pump and oil cylinder assure the sensitive control and reliability.

The forklift operates and shifts easily, steadily and no impaction realizing stepless or synchronized shifting, especially can replace the friction disc and pressure plate without dismantling and winching out of the engine.

Mounting with the descended safety valve in order to prevent the fork descending fast when it has trouble.
