Hydraulic Electric Skid Steer Loader , 20 ° Grade Ability Skid Steer Track Loader

China Hydraulic Electric Skid Steer Loader , 20 ° Grade Ability Skid Steer Track Loader supplier

Large Image :  Hydraulic Electric Skid Steer Loader , 20 ° Grade Ability Skid Steer Track Loader

Product Details:

Place of Origin: CHINA
Brand Name: KUDAT
Certification: CE/Ghost/Emark/ISO
Model Number: JC45

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Packaging Details: Naked Packing in Container
Delivery Time: 10 days after receipt of deposit or L/C
Payment Terms: Western Union, MoneyGram, L/C, T/T
Supply Ability: 2000 units per month
Detailed Product Description
Rated Power: 50 HP Rated Operating Capacity: 700 Kg
Bucket Capacity: 0.36 M3 - 0.45 M3 Weight: 2750 Kg
Max.Travel Speed: 12 M/h Grade Ability: 20 °
Tipping Load: 1400 Kg Lifting Force: 1600 Kg

Hydraulic Electric Skid Steer Loader , 20 ° Grade Ability Skid Steer Track Loader



4WD 50HP Power Skid Steer Loader JC45 With Bobcat Attachments Operating Weight 2750kg

Main Features of skid steer loader:

1) Good technical parameters with competitive price
2) maneuver in tight spaces, turn within its own length
3) a broad product line, innovative designs, and unsurpassed range of job-matched attachments.
4) Excellent reach & lift height for truck loading (vertical path).
5) more than 20 series attachments for option: pallet fork, swing blade, utility fork grapple, asphalt cutter, backhoe, hydraulic hammer, 4 in 1 bucket, auger, cultivator, and tooth bucket etc
6) attachment can be used with bobcat type skid loader
7) world famous hydraulic systems from America, Japan and Italy
8) famous brand engine with EPA or EC stage II or III from abroad and domestic
9) CE and ISO 9001 certificated
10) versatility, maneuverability and reliability





OPTIONAL:
1) PERKINS ENGINE, HYUNDAI ENGINE, DEUTZ ENGINE, LOVOLE ENGINE AND DOMESTIC ENGINE AND MORE
2) WITH OR WITHOUT HYDRAULIC SERVO(JOYSTICK SYSTEM)
3) ENCLOSED CAB WITH OR WITHOUT AIR CONDITIONER OR HEATER
4) ALL KINDS OF TIRES ( SOLIC, NORMAL, CACUUM) AND DIFFERENT TYPE FOR CHOICE
5) VARIOUS OF ATTACHMENTS



Specifications
Rated operating capacity(kg)          700
Tipping load(kg)                             1400
Bucket capacity(m3)                        0.36-0.45
Operationg weight(kg)             2600
Max. travel speed(km/h)                 12
Hydraulic pump flow(L/min)          62.5
Fuel tank capacity(L)                      50
Tires                                                     10.0/75-15.3
Overall dimensions(mm)                 3200×1740×2030
Dimensions
Height at maximum extension(mm) 3670
Height to bucket hinge pin(mm)         2900
Width with bucket(mm)                        1740
Track width(mm)                                                 1450
Wheelbase(mm)                                             991
Ground clearance(mm)                   185
Dump angle                                               40°
Dumping height(mm)                                   2310
Maximum reach(mm)                                   710
Engine
Maker/Model              XINCHAI 490BPG
Net power                  50hp/2650rpm
Type                           4 Cylinder in-line, Water cooled, 4 stroke, Diesel engine
Displacement(L) 2.54
Standard
Open-type operator cab
Hand control system(Mechanical type)
Standard bucket
Auxiliary hydraulic couplers
Optional
Enclosed operator cab with A/C
Cab fitted with a heater as standard
Hydraulic joystick controls
Attachments: Backhoe,Breaker,Angle blade,Auger,Sweeper,Pallet fork,Combinition bucket,Mower,Asphalt cutter,and More



Hydraulic Electric Skid Steer Loader , 20 ° Grade Ability Skid Steer Track Loader

Hydraulic Electric Skid Steer Loader , 20 ° Grade Ability Skid Steer Track Loader
