4 Hopper Concrete Mixer Machine , 25 m3/h Mobile Concrete Batching Plant

China 4 Hopper Concrete Mixer Machine , 25 m3/h Mobile Concrete Batching Plant  supplier

Large Image :  4 Hopper Concrete Mixer Machine , 25 m3/h Mobile Concrete Batching Plant

Product Details:

Place of Origin: China
Brand Name: KUDAT
Certification: CE/SGS/ISO9001
Model Number: YHZD25

Payment & Shipping Terms:

Minimum Order Quantity: 1Unit
Price: Negotiation
Packaging Details: Nude packing in container.
Delivery Time: 25-30 working days after received your payment
Payment Terms: D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1,000pcs per month
Detailed Product Description
Production: 25 M3 / H Conveyor Capacity: 200 Tons
Mixer Power: 18.5 KW Hopper Quantity: 4
Power Supply: 380V / 50HZ Trailed Speed: 15 KM / H
Wheel Distance: 2800 Mm Weight: 20000kg
Discharge Height: 2.8 M Turning Radius: 11 Mm

4 Hopper Concrete Mixer Machine , 25 m3/h Mobile Concrete Batching Plant



25 M3 / H Mobile Concrete Mixing Plant YHZD25 For Concrete Mixing Works

25 M3 / H Mobile Concrete Mixing Plant YHZD25 For Concrete Mixing Works

Specifications:




      Model

YHZD25

         Production (m3/h)

25

Mixer

Type

JD500



Power (kW)

1×18.5



Output (m3)

0.5



Grain Size (mm)

≤60

Batcher

Hopper Capacity(m3)

4



Hopper Quantity

4

Conveyor Capacity (t/h)

200



Aggergate(kg)

1000±2%

Weighing

Cement (kg)

300±1%

Scope

Water (kg)

200±1%

Accuracy

Admixture (kg)

20±1%

Trailed speed (km/h)

15

Wheel distance(outside)mm

2800

Turning radius mm

11

Total weight  (kg)

20000

Power(kW)

35

Discharge Height (m)

2.8



Brief introduction of the whole machine

YHZD25 Mobile Concrete Mixing Station which adopts advanced technologies and

 scientific researching results from home and abroad and combines our company’s years’ mixing station producing experience, which is a new type mobile concrete mixing station designed by our company independently. It is now one of the best mixers in China, which boasts compact and reasonable designing. Most functions of the mixing station are finished in the pulling chassis, combining aggregate, electrnic

 weighting, mixing and lifting together. It can be stopped to run or be pulled away

easily, which is convenient to move and easy to install. It is can be applied to

 various construction sites like road surface, bridges, dams and airports, and also

 like architectural workings, concrete product plant and commercial concrete

production.

Main features and functions of the system

1. It is equipped with centralized monitoring and VGA high definition colorized

   display. Hints of Chinese menu are legible and concise which are easy to

   understand and operate.

2 . Industrial PC is adopted as host computer which boasts strong anti-jamming              and reliable work.
