Multi Disc Brake Pavement Grinder Machine , Depth Control Asphalt Concrete Milling Equipment

China Multi Disc Brake Pavement Grinder Machine , Depth Control Asphalt Concrete Milling Equipment supplier

Large Image :  Multi Disc Brake Pavement Grinder Machine , Depth Control Asphalt Concrete Milling Equipment

Product Details:

Place of Origin: China
Brand Name: XCMG
Certification: ISO9001:2008, CE
Model Number: XM130K

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Naked packing in container
Delivery Time: 10 working days after received L/C or your deposit
Payment Terms: L/C at sight, T/T or western Union
Supply Ability: 1500 units per month
Detailed Product Description
Product Name: Cold Milling Machine Rated Power: 194kw
Max. Milling Depth: 315mm Max. Milling Width: 1320mm
Travel Speed: 0-7km/h Operating Speed: 0-30m/min
Drum Diameter With Tools: 980mm Operating Weight: 20000kg

Multi Disc Brake Pavement Grinder Machine , Depth Control Asphalt Concrete Milling Equipment





XCMG Construction Equipments 194KW Asphalt road Cold Milling Machine XM130K With 1320MM Max. Milling Width



XM Series milling machine is one of the main asphalt concrete road maintenance equipment, mainly used for large-scale highways, urban roads, airports, freight yard, etc for renovation of asphalt pavement. One-time removal of entire concrete overlay. It can also be used for cleaning protuberance, oil layers, retieulation and vehicle tracks as well as road trench, tunnel excavation. cement road surface roughening and dislocation smothness.
The equipment features advanced performance, high efficiency, simple process, easy control of milling depth, flexible operation, good maneuverability and the old material recycling and utilization. It is an ideal equipment for pavement maintenance and renovation.



Performance and characteristic:

1. The milling drum is driven by two four-link belts with automatic tensioning drvice.

2. The moving system is the four-wheel fully hydraulic driving .The differential lock makes uniform driving

forces even on the slippery road surface.

3. The machine has the advantages of being suitable for different milling materials and milling depth,

optimizing power output automatic adjusting function and implementing maximization of the productivity.

4. The brake system implements the travelling brake by the reverse dragging of the hydraulic system.The

multi-disc typed brake is arranged on the rear wheel reducer to implement the parking brake. The automatic

depth control (selectable )adopts the contact-typed or non contact-typed sensor for detection with digitally displayed milling depth



Specification:

Model



XM130K



Max. milling with

mm

1320



Max. milling depth

mm

315

Milling wheel

Number of tools



112

Drum diameter with tools

mm

980

Engine

Model



6CTA8.3-C260

Rated power

kW

194

Rated speed

rpm

2100

Specifications

Operating speed

m/min

0~30

Travel speed

km/h

0~7

Ground clearance

%

50

Ground clearance

mm

≤200

Operating weight

kg

20000

Volume

Fuel tank

L

280

Hydraulic oil tank

L

160

Water tank

L

780

Conveyor

Width

mm

600

Measurement

Overall machinery LxWxH

mm

5255×2480×3245

Conveyor LxWxH

mm

7020×1030×900

Travel mode



Tire
