0.6 CBM Rated Bucket Front End Wheel Loader , 37KW Rated Power Four Wheel Loader

China 0.6 CBM Rated Bucket Front End Wheel Loader , 37KW Rated Power Four Wheel Loader supplier

Large Image :  0.6 CBM Rated Bucket Front End Wheel Loader , 37KW Rated Power Four Wheel Loader

Product Details:

Place of Origin: CHINA
Brand Name: KUDAT
Certification: CE/EMARK/GHOST/ISO
Model Number: ZL12F

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Naked packing in container
Delivery Time: 10 working days after received L/C or your deposit
Payment Terms: L/C at sight, T/T or western Union
Supply Ability: 1200 units per month
Detailed Product Description
Product Name: Wheel Loader Rated Power: 37KW
Rated Loading Weight: 1.2 Ton / 1200KG Operating Weight: 3100KG
Rated Bucket Capacity: 0.6 CBM Reach Distance: 1020 Mm
Dumping Height: 2650 Mm Max.break Out Force: 36 KN

0.6 CBM Rated Bucket Front End Wheel Loader , 37KW Rated Power Four Wheel Loader





1200 kg  capacity 0.6M3 Bucket 4WD mini Wheel Loader ZL12F with new hood



Features
1. The wheel loader uses a hydro-mechanical transmission which can make full use of engine power, and can have an automatic variable transmission according to the external resistance. It avoids power failure of the engine due to the suddenly increased external load. The wheel loader can absorb and eliminate the vibration and impact of external load on engine. It protects the drive system and engine, increases the service life, and facilitates the operation and achieves higher economical and production efficiency.


2. The wheel loader uses the central articulated frame and load sensing hydraulic steering gear. The machine can achieve short turning radius and superposition of the front and rear tracks upon turning (this will ensure safe driving). The wheel loader has the advantages of easy operation on narrow sites, flexible operation, safety, convenient maintenance and so on.


3. The wheel loader uses four-wheel drive, low-pressure wide base off-road tires and an oscillating rear axle, so it has sound off-road performance, good traffic ability and larger traction.


4. The wheel loader is equipped with a single-pipe type hydraulic four-wheel brake.


5. The wheel loader has a fully enclosed cab and the seats have the functions of vibration reduction and easy adjustment. The wheel loader offers the driver a comfortable drive and wide view.



Main Technical Parameter of ZL12F

Item

Parameter

Rated load (kg)

1200

Bucket capacity (m3)

0.6

Wheel tread (mm)

1400

Wheel base (mm)

2005

Min turning radius (mm)

4500

Min ground clearance (mm)

260

Dumping height (mm)

2650

Corresponding dumping reach (mm)

1020

Lifting time (s)

4

Hydraulic cycle time (s)

8.5

Maximum excavating force (KN)

36

Drive mode

Four Wheel Drive

Machine weight (kg)

3100

Overall dimensions (mm) (Length*width*height)

4800*1730*2720

Engine model

Changchai4L68

Rated power of engine (kw)

37

Rated speed of engine (rpm)

2200
